F405 Flight Controller

FPV Electronics > Flight Controller

$30.90
$40.90
The F405 Flight Controller is a high-performance flight control system designed for FPV drones and UAV applications.
SKU: CRP00885
Package weight: 0.10 KG
Pkg. Size: 55MM*55MM*20MM
IN STOCK
To Wishlist
Add to Cart



F405 Flight Controller Technical Brief

Descriptions

The F405 Flight Controller is a high-performance flight control system designed for FPV drones and UAV applications. Built around the STM32F405 microcontroller (ARM Cortex-M4 @ 168MHz), it provides reliable flight control with optimized processing efficiency. Suitable for racing drones, freestyle FPV, and intermediate autonomous operations.

1. Main Specifications

ComponentDetails
ProcessorSTM32F405 (Cortex-M4 @ 168MHz, FPU)
Memory192KB SRAM + 1MB Flash
IMUICM42688-P
BarometerBMP280 (Pressure sensor precision: ±0.12 hPa)
Connectivity6×UART / 8×PWM /3×GPIO / 1×I2C
FLASH16M black box
Input Voltage2S-8S LiPo (7.4V-25.2V)
BEC Outputs5V@3A + 9V@2A (Non-isolated)
Dimensions36×36mm (30.5×30.5mm mounting)
Board Weight9g

2. Key Features

  • • 4kHz Control Loops: 250μs cycle time with Cortex-M4 FPU

  • • Redundant Sensor Bus: SPI + I2C IMU connectivity options

  • • Single CAN Bus: Supports ESC telemetry (e.g., BLHeli_32)

  • • 6S LiPo Support: 30V input with reverse polarity protection

  • • Onboard OSD: MAX7456 with basic HUD customization

  • • SBUS/CRSF Support: Compatible with major RC protocols

3. Firmware Compatibility

✅ Betaflight (Firmware version:4.4.3BTFL)

4. Typical Applications

🚁 Racing Drones:

  • • Gyroscope 8KHz refresh rate

🎥 Freestyle FPV:

  • • Stable gyro performance for acrobatic maneuvers

⚡ Lightweight UAVs:

  • • Supports 3S to 8S power kit

5. Accessories Package

  • • 1x SH1.0-8pins silicone cable (7cm, reversed)

  • • 1x SH1.0-6pins silicone cable (12cm, reversed)

  • • 1x SH1.0-4pins silicone cable (12cm, reversed)

  • • 1x SH1.0-3pins silicone cable (10cm, reversed)

  • • 1x SH1.0-2pins silicone cable (12cm, single-end)

  • • 5x M3*10mm shock-absorbing balls

6. Connection Diagram
