The UBLOX M10 timing module integrates u-blox's 10th-generation GNSS technology with precise 1PPS (Pulse Per Second) output, designed for applications requiring nanosecond-level synchronization. Supporting concurrent GPS, Galileo, GLONASS, and BeiDou reception, it delivers <2.0m CEP positioning accuracy and ±30ns timing precision in a compact industrial-grade package. Ideal for telecommunications, power grid synchronization, and scientific instrumentation:cite[3]:cite[4]:cite[7].
| Parameter | Technical Value |
| GNSS Platform | u-blox M10 |
| Supported Systems | GPS L1, Galileo E1, GLONASS L1, BeiDou B1, QZSS, SBAS |
| Timing Accuracy | ±30ns RMS (1PPS output) |
| Positioning Accuracy | 1.5m CEP (SBAS enabled) |
| Update Rate | 1–25Hz (position), 1Hz (1PPS) |
| Sensitivity | Tracking: -166dBm, Acquisition: -148dBm |
| Voltage Range | 3.0V–5.5V DC (built-in LDO) |
| Interfaces | UART, I²C, SPI, 1PPS dedicated output |
| Antenna Support | Active ceramic patch + external SMA port |
| Dimensions | 15×15×5.2mm (compact), 50×14.4mm (standard) |
| Weight | 2.6g (compact), 32g (standard) |
• Precision Timing Engine:
TCXO-stabilized 1PPS output with ±30ns jitter for 5G base station synchronization:cite[4]:cite[7].
• Multi-Constellation Resilience:
Concurrent quad-system tracking (GPS/Galileo/GLONASS/BeiDou) ensures signal availability in urban canyons:cite[3]:cite[6].
• Ultra-Low Power Modes:
• Continuous Tracking: 12mW
• Super-E Mode: 3mW (monthly battery life for IoT trackers):cite[5]:cite[8].
• Anti-Jamming Technology:
Embedded RF filters and Galileo OS-NMA spoofing detection:cite[6]:cite[8].
• Thermal Compensation:
-40°C to +85°C operation with ±0.01ppm frequency stability:cite[4].
| Metric | Performance | Conditions |
| 1PPS Jitter | ±30ns RMS | 50Ω load |
| Cold Start TTFF | ≤28s | All systems enabled |
| Time-To-First-Fix (TTFF) | 0.1s (hot start) | Backup capacitor assisted |
| Velocity Accuracy | 0.01m/s | 10Hz update rate |
| Mode | Current | Use Case |
| 25Hz High Precision | 25mA | Base station synchronization |
| 1Hz Timing Only | 12mA | Power grid monitoring |
| Super-E Sleep | 900μA | Monthly asset tracking |
• 5G/TDD base station timing synchronization
• Fiber-optic network timestamping
• Smart grid phase measurement units (PMUs)
• Substation fault recording synchronization
• Radio telescope array timing
• Seismic monitoring networks
• Flight data recorder timestamping
• Rocket telemetry systems
• Temp Range: -40°C to +85°C (operational):cite[2]:cite[4]
• Vibration Immunity: 5Grms (10–500Hz, MIL-STD-810G):cite[4]
• Humidity Resistance: 95% non-condensing
• EMC Compliance: EN 303 413, FCC Part 15B:cite[3]
