The 5.8G Lollipop Antenna V4 delivers enhanced signal stability and reduced multipath interference for FPV video transmission systems. Engineered with advanced circular polarization and broadband tuning, it provides reliable video clarity in racing drones, cinematic platforms, and long-range exploration. Compatible with DJI Goggles, WIRECARE, and MAMMOTH VTX systems, its robust construction ensures consistent performance during high-G maneuvers and in challenging environmental conditions.
| Parameter | Specification |
| Frequency Range | 5.500–5.950 GHz |
| Polarization | RHCP/LHCP (Switchable) |
| Gain | 2.6 dBi |
| VSWR | ≤1.07 (Center Frequency) |
| Axial Ratio | <3 dB |
| Connector Types | RP-SMA / SMA / MMCX / UFL |
| Max Input Power | 50W |
| Cable Length | 15cm RG316 (Low-Loss) |
| Weight | 5.5–7.1g (Length-dependent) |
| Dimensions | Ø38mm × 60/105/145mm (Diameter × Height) |
• Broadband Tuning: Covers 5.5–6.0 GHz for global FPV channel compatibility
• Dual Polarization: Switchable RHCP/LHCP for transmitter/receiver matching
• Impact Resistance: PC+ABS housing withstands 100G crash impacts
• Signal Integrity: ≤1.07 VSWR minimizes reflection and power loss
• Omnidirectional Coverage: 360° horizontal beam width for agile flight
| Environment | Range | Signal Clarity | Obstacle Penetration |
| Open Field | 2.5 km | 98% | Low |
| Urban Area | 800 m | 85% | Moderate |
| Forest | 500 m | 75% | High |
| Racing Track | 300 m | 95% | Low |
• DJI FPV Goggles V1/V2 analog conversion modules
• MAMMOTH high-power VTX systems for long-range
• WIRECARE HDZero/freestyle quadcopters
• Diversity receivers (e.g., RapidFIRE, FPVspeed)
• Portable monitor setups with RP-SMA interfaces
• MultiGP racing events requiring low-latency video
• Industrial drones operating in RF-noisy environments
• Operating Temperature: -40°C to +60°C
• Weather Resistance: IPX4-rated (Splash-proof)
• UV Stability: Housing maintains integrity after 500+ sun hours
• Wind Resistance: Stable performance at 120 km/h airspeeds
