Big Motors > LandDrive (Ebike/Robots)
The BL3150L 1310KV internal rotor brushless motor delivers high-speed precision for garden electric tools and smart shearing robots. Engineered with reinforced construction and thermal management, it provides exceptional cutting performance while maintaining efficiency. The motor's optimized magnetic circuit and sealed design ensure reliable operation in demanding outdoor environments with minimal vibration for precise cutting applications.
| Parameter | Specification |
| Motor Type | 3-Phase Sensored BLDC (Internal Rotor) |
| Protection Rating | IP55 (Dust/Water Jet Protected) |
| Rated Voltage | 16.8V (6S Li-ion) |
| Continuous Power | 850W @ 22.2V (Peak 1900W) |
| Max Torque | 26Nm (Peak) / 1.1Nm (Continuous) |
| Speed Range | 22500RPM (ESC Adjustable) |
| KV Rating | 1310 RPM/V |
| Phase Resistance | 0.025Ω (Phase-to-Phase) |
| Shaft Diameter | 4mm (Hardened Steel, D-Cut) |
| Weight | 130g |
| Mounting | 25×25mm / M3 Threads (4-point) |
• High-Speed Cutting: 0-40k RPM acceleration in 0.2 seconds
• Anti-Jam Protection: Auto-reverse function on stall detection
• Weather Resistance: Conformal-coated PCB + hydrophobic seals
• Vibration Control: Precision-balanced rotor (<0.3g imbalance)
• Smart Integration: CAN bus interface for robotic control systems
| Blade Type | RPM | Cutting Force | Efficiency |
| Straight Blade | 25,000 | 120N | 89% |
| Serrated Blade | 18,000 | 150N | 86% |
| Rotary Cutter | 35,000 | 80N | 91% |
• Electric hedge trimmers
• Cordless grass shears
• Robotic lawn edgers
• Autonomous pruning robots
• Robotic topiary sculpting tools
• Vineyard maintenance machines
• Pole saw attachments
• Compact chainsaw drives
• Brush cutter mechanisms
• Continuous Operation: 65°C @25°C ambient (Class H insulation)
• Thermal Management: Aluminum heat sink fins + axial airflow channels
• Protection System: Step-throttling at 85°C → cutoff at 105°C
• Storage Conditions: -30℃ ~ +85℃, <90% RH
