The DX2808 1500KV brushless motor delivers exceptional high-RPM performance for competitive FPV racing drones and speed-focused RC models. Engineered with precision-balanced titanium components and low-resistance windings, it provides explosive acceleration and sustained power for track domination. The motor's aerodynamic design, advanced thermal management, and ultra-responsive throttle control ensure peak performance in high-G maneuvers and speed runs exceeding 160km/h.
| Parameter | Specification |
| Motor Type | 3-Phase Sensorless BLDC |
| Protection Rating | IP43 (Dust & Splash Protected) |
| Rated Voltage | 4S-6S LiPo (22.2V) |
| Continuous Power | 1032W @ 22.2V |
| Max Torque | 1.3Nm (Peak) / 0.8Nm (Continuous) |
| Speed Range | 10,000–58,000 RPM (ESC Adjustable) |
| KV Rating | 1500-1900 RPM/V |
| Phase Resistance | 0.015Ω (Phase-to-Phase) |
| Shaft Diameter | 5.0mm (Titanium Alloy) |
| Weight | 53g |
| Mounting | 16×19mm / M3 Threads (4-point) |
| Dimensions | Ø28mm × 8mm (Stator Diameter × Height) |
• Racing Tuned: Optimized for 4"-6" FPV racing drones
• Ultra-Low Resistance: Gold-plated terminals minimize power loss
• High-Speed Bearings: Hybrid ceramic bearings rated for 65,000 RPM
• Vortex Cooling: CNC-machined aluminum housing with turbulence fins
• Instant Acceleration: 0-55k RPM in 0.07 seconds
| Application | Voltage | Propeller | Thrust | Efficiency |
| 5" FPV Racer | 22.2V (6S) | HQProp 5×4.3×3 | 1930g | 91% |
| 4" Micro Racer | 22.2V (5S) | Gemfan 4023 | 980g | 88% |
| 6" Freestyle | 22.2V (4S) | Ethix S6 | 1520g | 90% |
| Speed Run Boat | 22.2V (6S) | 40mm impeller | 0.95Nm | 84% |
• 4"-6" competition racers (>160km/h)
• MultiGP open-class builds
• Drone racing league (DRL) spec models
• EDF jet propulsion systems
• Pylon racing planes
• Wing-type FPV platforms
• 1:8 scale RC speed runners
• Drag racing power systems
• Hydroplane RC boats
• Continuous Operation: ≤85°C @ 25°C ambient (3-sec burst to 100°C)
• Cooling Requirements: Minimum 10m/s airflow (prop wash sufficient)
• Thermal Protection: Dynamic power reduction at 115°C
• Storage Conditions: -20°C to +70°C, <80% RH
