Electric Scooter Headlight

Accessories > Scooter Accessories

$7.90
High‑brightness LED headlight designed for electric scooters, e‑bikes and PEVs. Compact aluminium housing with universal mounting bracket, wide voltage compatibility, and multiple beam modes for safe night riding.
SKU: 4621
Package weight: 1.00 KG
IN STOCK
To Wishlist
Add to Cart



Electric Scooter Headlight Product Specifications

High‑brightness LED headlight designed for electric scooters, e‑bikes and PEVs. Compact aluminium housing with universal mounting bracket, wide voltage compatibility, and multiple beam modes for safe night riding.

1. Key Electrical Parameters

  • • Operating Voltage: 12V – 72V DC (compatible with 24V, 36V, 48V, 60V, 72V systems)

  • • LED Power: 10W – 30W (dependent on model configuration)

  • • Luminous Flux: 800 – 2000 lumens

  • • Beam Pattern: Low beam + high beam (or single beam with cutoff line)

  • • Colour Temperature: 6000K – 6500K (cool white)

  • • Current Consumption (Typical): 0.8A – 2.5A @ 12V

2. Hardware Design & Construction

  • • Housing Material: Die‑cast aluminium alloy (anodised black or silver)

  • • Lens Material: Toughened glass or high‑transparency PC (polycarbonate)

  • • Heat Dissipation: Integrated passive cooling fins (no fan required)

  • • Dimensions (Typical): 80mm (L) × 45mm (W) × 40mm (H) (may vary by model)

  • • Weight (Typical): 120g – 180g

  • • Mounting Bracket: Adjustable handlebar clamp (fits 22mm / 7/8‑inch to 31.8mm handlebars)

3. Features & Interfaces

  • • Light Source: High‑performance SMD or COB LED chips (rated lifespan 30,000+ hours)

  • • Beam Modes: High beam, low beam, strobe / SOS (mode switching via external momentary switch)

  • • Wiring Interface: 2‑wire or 3‑wire cable (Red = positive V+, Black = ground, Yellow/White = mode control)

  • • Connector Type: Waterproof SM‑2P or aviation connector (customizable per request)

  • • Mounting Orientation: Handlebar centre or offset mounting (left/right side adjustable)

  • • Optional Features: Daytime running light (DRL) strip, horn integrated, brake light function

4. Protection & Environmental Features

  • • Waterproof Rating: IP65 (dust‑tight and protected against low‑pressure water jets)

  • • Operating Temperature Range: -20°C to +60°C

  • • Vibration Resistance: Suitable for daily urban and light off‑road riding

  • • Short Circuit Protection: Reverse polarity protection built‑in
