Big Motors > LandDrive (Ebike/Robots)
The H6368-280KV sensored brushless motor delivers precision torque control for electric scooters and automated luggage systems. Featuring integrated Hall sensors and a compact form factor, it provides smooth sinusoidal operation with rapid response characteristics. The motor's reinforced construction and thermal management ensure reliable performance in urban mobility applications requiring frequent start-stop cycles and variable loading conditions.
| Parameter | Specification |
| Motor Type | 3-Phase Sensored BLDC |
| Protection Rating | IP65 (Dust/Water Jet Protected) |
| Rated Voltage | 36V DC (10S Li-ion) |
| Continuous Power | 480W @ 36V (Peak 3240W) |
| Max Torque | 3.5Nm (Peak) / 2.2Nm (Continuous) |
| Speed Range | 500-10000 RPM (FOC Adjustable) |
| KV Rating | 280 RPM/V |
| Phase Resistance | 0.035Ω (Phase-to-Phase) |
| Shaft Diameter | 4mm (Hardened Steel, D-Shaft) |
| Weight | 745g |
| Mounting | 20×20mm / M3 Threads (4-point) |
• Precision Control: Quad Hall sensors with 0.5° positioning accuracy
• Instant Response: 0-8000 RPM acceleration in 0.25 seconds
• Compact Integration: Stackable design with through-shaft wiring
• Anti-Jam Protection: Auto-reverse function on stall detection
• Smart Sleep Mode: 10μA standby current with motion-activated wakeup
| RPM | Torque | Efficiency | Power Output |
| 3000 | 2.0Nm | 92% | 628W |
| 6000 | 1.5Nm | 89% | 942W |
| 9000 | 0.8Nm | 83% | 754W |
• Compact folding scooter drives
• Last-mile delivery robots
• Self-balancing transporter wheels
• Remote-controlled suitcase motors
• Auto-following travel trolleys
• Airport baggage handling robots
• Warehouse cart propulsion
• Hospital bed movers
• Library book return systems
• Continuous Operation: 60°C @25°C ambient (Class F insulation)
• Thermal Protection: PTC cutoff at 85°C with auto-recovery
• Cooling Requirements: Natural convection (5m/s airflow recommended)
• Storage Conditions: -30℃ ~ +85℃, <90% RH
